Source-linked configuration dossier
Dominion Democracy Suite 5.17 / ImageCast X
A source-linked dossier for the ImageCast X ballot-marking device within EAC-certified Democracy Suite 5.17, including certified device alternatives, external UPS options, version observations, Pro V&V results, and EAC-hosted post-certification advisories.
Federal certificate DVS-DemSuite5.17VVSG 1.0VSTL: Pro V&V, Inc.Editorial: published r6
Do not collapse evidence scopes.
A certified component list does not prove what a jurisdiction installed. A jurisdiction system-version listing does not prove device firmware, change adoption, internal parts, networking state, or power topology.
Dossier overview
Start with the question you need to answer
Each section has its own shareable URL. Sources and caveats stay attached to every claim.
ComponentsAccessible parts list and optional 3D schematicOpen section TopologySource-linked topology, external pathways, controls, and gapsOpen section HistoryVersions, changes, findings, power, and deploymentsOpen section Usage2024 product-family and manufacturer contextOpen section SourcesGrouped archived source manifestOpen section
DVS-DemSuite5.17, certified 2023-03-16.
A physical interface is not evidence that an external peer was connected, enabled, or used in a jurisdiction.
Named-family observations across 15 states.
Grouped at manufacturer scope; not counted as exact dossier usage.
